1. 7000 rpm high speed fanto quickly cool down the camera.
2. Built-in battery, supports up to approximately 180minutes of maximum power, and allows for use while charging.
3. Two-speed adjustable to meet different needs.
4. Multiple protections ensure safer usage.
5. Quick mounting and dismounting design, easy to use the cooling fan and camera’s LCD screen storage.
Note:
1. After installing this product, the camera's LCD screen will not be able to be stowed. If you need to store the LCD screen, please remove the coolingfanfirst.
2. This product is not waterproof; please do not store or use it in a humid environment.
3. Do not blockthe air inlet or outlet when the cooling fanis in operation.
4. When not in use, press and hold the power switch for about 3seconds to turn off the device.
Power Switch:
Click to display battery level
Press and hold for about 3 seconds to switch the cooling fan on or off.
Battery Indicator Light:
Operating Status:
4 lights illuminated: Battery level 75%–100%
3 lights illuminated: Battery level 50%–75%
Two lights illuminated: Battery level 25%–50%
One light illuminated: Battery level 10%–25%
One light flashing: Battery level <10%
Charging Status:
Four indicator lights illuminate sequentially, then one of them flashes: Charging in progress.
All four lights steady: Fully charged
Gear Indicator Light:
L: Normal Mode
H: Enhanced Mode
Both indicator lights flashing simultaneously: Abnormal condition
Sony: FX3 / FX30 / Alpha 7 IV / Alpha 7S III / Alpha 7C II / Alpha 7CR / Alpha 7C / Alpha 6700 / ZV-E1 / ZV-E10 / ZV-E10 II / ZV-1 / ZV-1F
Canon: EOS R5 / R5 Mark II / R6 V / R6 Mark III / R7
Packing List
1 x cooling fan
1 x USB-C Cable
1 x Operating Introduction
1 x Guarantee Card
Technical Data
Battery Parameter:3.7V / 1100mAh / 4.07Wh
Input:5V=2A;10W
Operating Voltage:5V
Operating Current:0.2~0.4A
Operating Power:1~2W
Fan Noise:36.6~40.9dB
Fan Speed:4500~7000RPM
Operating Temperature:
Charging Temperature: 0℃ to 45℃ / 32°F to 113°F
Discharging Temperature:-15℃ to 60℃ / 5°F to 140°F
Product Dimensions:85.0 × 50.8 × 25mm / 3.3 × 2.0 × 1.0 in
Package Dimensions:155.0 × 81.5 × 42.0mm / 6.1 × 3.2 × 1.7 in
Product Weight:102.5 ± 5.0g / 3.6 ± 0.2oz
Package Weight:139.5 ± 5.0g / 4.9 ± 0.2oz
Material(s): PC, Aluminum Alloy
